Based in Pune(India), we have garnered wide acclaim for making available quality and cost effective products to the lengths and breadths of the country. We follow pre-defined quality rules to make sure that the offered array of products is as per the exact customers' demand and need.

The VEGAFLEX 81 level sensor measures maintenance-free all kind of liquids. Even in applications with vapour, buildup, foam generation and condensation, the sensor delivers precise and reliable measured values. The VEGAFLEX 81 is the economical solution for various level and interface measurements.

Application area :  With VEGAFLEX 81 you can measure all kinds of liquids essentially maintenance free. The sensor delivers precise and reliable measured values even in applications with steam, buildup, foam generation or condensation. VEGAFLEX 81 is a truly cost-effective level and interface sensor for your measuring task.

Your benefit

• The guided adjustment enables a simple, time-saving and reliable setup
• Shortenable probes offer a simple standardisation and highest flexibility in the planning
• Comprehensive diagnostic possibilities ensure a maintenance-free operation and hence a high plant availability

Function : High frequency microwave pulses are coupled onto a cable or rod and guided along the probe. The pulse is reflected by the product surface. The time from emission to reception of the signals is proportional to the level in the vessel.

Measuring range

• Cable probe up to 75 m (246.1 ft)
• Rod probe up to 6 m (19.69 ft)

Operating voltage

• Version for low voltage 9.6 - 48 V DC, 20 - 42 V AC, 50/60 Hz
• Version for mains voltage 90 - 253 V AC, 50/60 Hz

Materials : The wetted parts of the instrument are made of stainless steel. The instrument seal is made either of FKM, FFKM or EPDM.

Housing versions : The housings are available as double chamber version in plastic, stainless steel or Aluminium. They are available in protection class IP 66/ IP 67.

Electronics versions : The instruments are available in different electronics versions. Apart from the two-wire electronics with 4 - 20 mA/HART, a four-wire version and two purely digital versions with Profibus PA and Foundation Fieldbus are available.

Operation : The adjustment of the instrument is carried out via the optional display and adjustment module PLICSCOM or via a PC with the adjustment software PACTware and corresponding DTM. Further adjustment options are available via HART communicator as well as manufacturerspecific programs such as AMS™ or PDM.

Version

• Basic version for exchangeable cable ø 2; ø 4 mm
• Basic version for exchangeable rod ø 8 mm
• Basic version for exchangeable rod ø 12 mm
• Coax version ø 21.3 mm for ammonia application
• Coax version ø 21.3 mm with single hole
• Coax version ø 21.3 mm with multiple hole
• Coax version ø 42.2 mm with multiple hole
• Exchangeable rod ø 8 mm
• Exchangeable rod ø 12 mm
• Exchangeable cable ø 2 mm with gravity weight
• Exchangeable cable ø 4 mm with gravity weight
• Exchangeable cable ø 2 mm with centering weight
• Exchangeable cable ø 4 mm with centering weight
• Exchangeable cable ø 4 mm without weight exchangeable, PFA-coated cable ø4 mm with non-coated centering weight

Materials, wetted-parts

• PFA
• 316L
• Alloy C22 (2.4602)
• Alloy 400 (2.4360)
• Alloy C276 (2.4819)
• Duplex (1.4462)
• 304L

Seal-material

• EPDM
• FKM
• FFKM
• Silicone FEP coated
• Borosilicate glass

Housing-material

• Plastic
• Aluminium
• Stainless steel (precision casting)
• Stainless steel (electropolished)

Protection-rating

• IP 66/IP 68 (0.2 bar)
• IP 66/IP 67
• IP 66/IP 68 (1 bar)

Output

• Profibus PA
• Foundation Fieldbus
• 4- 20 mA/HART - two-wire
• Modbus
• 4 - 20 mA/HART - four-wire

The ace for level measurement and interface measurement in all liquids : The VEGAFLEX 81 guided radar sensor is exceptional when it comes to measuring the level or interface of liquids. Guided radar is extremely versatile and can be found in almost every industrial sector. Whether bitumen or liquefied gas, in storage containers or standpipes, in a metering tank or in tank farms – VEGAFLEX 81 measures the level or interface (separation layers) of liquids with great reliability and accuracy. Guided radar delivers reliable measurements data for control or safety systems for

• Level measurement in ammonia storage tanks
• Level measurement in standpipes
• Interface measurement in storage tanks, bypass tubes, standpipes

Passive RFID Pressure Transponder (Series 21 D RFID)

• Provides pressure, test point numbers, temperature and device information.
• Energy supply via RFID interface, usable for an unlimited period without maintenance.
• Comfortable read out and forwarding of measurement data.
• Extremely resistant to environmental influences and vandalism.
• Pressure Ranges from 3 to 1000 bar.

Data Logger RFID (Series 21 DC RFID)

• Saves up to 8000 pressure-and temperature values.
• Integrated long-life battery for autonomous data logging.
• Total Error Band ± 0,5 %FS @ 0...50 °C.
• Passive RFID interface 13,56 MHz / ISO 14443.
• Integrated low-power I2C pressure transmitter also available as OEM

Application area : The VEGAPULS 64 is a sensor for continuous level measurement of liquids. With small tanks or in case of narrow space the small process fittings offer special advantages. The very good signal focusing enables the use in vessels with many installations such as e.g. stirrers and heating spirals.

Your benefit

• Exact measuring results independent of process conditions
• High plant availability, because wear and maintenance-free
• Maintenance-free operation through non-contact measuring principle

Function : The sensor emits a continuous radar signal through the antenna. The emitted signal is reflected by the medium and received as an echo by the antenna. The frequency difference between the emitted and received signal is proportional to the distance and depends on the filling height. The determined filling height is converted into a respective output signal and outputted as measured value.

Version

• With plastic horn antenna ø 80 mm
• Thread with integrated horn antenna
• Flange with encapsulated antenna system
• Hygienic fitting with encapsulated antenna system

Materials :  The wetted parts of the instrument are made of 316L, PP, PTFE or PEEK. The process seal is made of FKM, FFKM, EPDM or PTFE.

Housing versions :  The housings are available as single chamber or double chamber version in plastic, stainless steel or aluminium. They are available with protection ratings up to IP 68 (1 bar).

Electronics versions : The instrument is available with electronics 4 - 20 mA/HART as well as HART and power pack.

Adjustment

• Adjustment on the measurement loop : The adjustment of the instrument is carried out via the optional display and adjustment module PLICSCOM or via a PC with the adjustment software PACTware and corresponding DTM.
• Wireless adjustment via Bluetooth : The Bluetooth version of display and adjustment module enables a wireless connection to standard adjustment units. This can be smartphones/tablets with iOS or Android operating system or PCs with PACTware and Bluetooth USB adapter. Adjustment is hence carried out via a free-of-charge app from the Apple App Store or the Google Play Store or the adjustment software PACTware and respective DTM.
• Adjustment via remote systems : Further adjustment options are possible via a HART Communicator as well as manufacturer-specific programs such as AMS™ or PDM.

Materials, wetted-parts

• PFA
• PTFE
• 316L
• Alloy C22 (2.4602)
• PEEK

Hygenic-fittings

• Clamp ≥ 2", DN50 - DIN32676, ISO2852
• Slotted nut ≥ 2", DN50 - DIN 11851
• DRD connection ø 65 mm
• for NEUMO BioControl D50 PN16 / 316L

Seal-material

• EPDM
• FKM
• FFKM

Housing-material

• Plastic
• Aluminium
• Stainless steel (precision casting)
• Stainless steel (electropolished)

Protection-rating

• IP 66/IP 68 (0.2 bar)
• IP 66/IP 67
• IP 66/IP 68 (1 bar)

Application area : Liquids [density: > 0.5 … 2.5 g/cm³ (0.018 … 0.09 lbs/in³)] : The VEGASWING 51 is a universal level switch with small dimensions for use in liquids. Independent of the mounting position, it detects reliably with millimetre accuracy the limit level. The instrument can be used as empty or full detector, as approved overfill protection, dry run protection or pump protection in vessels and pipelines. The VEGASWING 51 is an economical solution with maximum reliability and safety.

Function : The heart of the sensor is the vibration drive by which the tuning fork is energized to vibrate at its resonance frequency. When covered with medium, the frequency of the fork decreases. This frequency change is processed by the integrated electronics and converted into a switching command. With the tuning fork with only 38 mm length, the VEGASWING work reliably independent of the installation position in any liquid. Pressure, temperature, foam, viscosity and the composition of the liquid do not influence the switching accuracy.

Your benefit

• Precise and reliable function due to product-independent switching point
• Low maintenance costs
• Minimum time and cost expenditure thanks to simple setup without medium

Materials : The wetted parts of the instrument are made of stainless steel 316L. The supplied process seal is made of Klingersil C-4400

Housing versions :

• The instruments are available in different temperature versions and as hygienic version.
• The housing is made of 316L and plastic PEI.
• The different versions are available up to protection IP 67.

Electronics versions

• The instruments are available in two different electronics versions.
• Apart from the electronics with transistor output (PNP), a version with contactless electronic switch is also available.

Operation : No adjustments on the instrument are necessary. The switching function is determined by the electrical connection.

Version

• Standard
• Extended temperature range
• Hygienic applications

Hygenic-fittings

• Clamp ≥ 1" - DIN32676, ISO2852
• Slotted nut ≥ DN25 - DIN 11851
• Hygienic fitting F40 with compression nut
• SMS DN38

Housing-material

• Plastic
• Stainless steel

Protection-rating

• IP 67
• IP 65
• IP 68 (0.2 bar)

Output

• Contactless electronic switch
• Transistor (NPN/PNP)
